Product Details:
|
| Name: | High Performance Carbide Hob For Bevel Gear Cutting Machine | Type: | Carbide Hob |
|---|---|---|---|
| Material: | Tungsten Carbide / Smelting High Speed Steel / Powder Metallurgy | Standard: | German Standard |
| Precision: | AAA,AA,DIN3968 | Application: | Carbide Hob For Straight Bevel Gears Cutting , End Gears Cutting, Spiral Bevel Gear Cutting |
| Coating: | TiN, AT, AP | Usage: | Gleason Cutting Machine / OERLIKON Bevel Gear Cutting Machine |
| High Light: | High Performance Carbide Hob M1,Bevel Gear Cutting Machine Carbide Hob,ISO Carbide Gear Hobbing Tool |
||
Integral carbide hobs improve performance for high speed and dry cutting applications,
including everything from standard carbide hobs to worm gear cutters
Gear Hob for straight bevel gears cutting , end gears cutting, spiral bevel gear cutting
Module: m0.2-m30,DP,CP, Single/multi starts, Straight/helix angle for any kind of hobs, and suitable for dry and wet cutting.
Types: Gear,Spline,Worm Gear,Chain Sprocket,Rack,Special Form
Patterns: Finishing,Roughing,Pre-shaving,Pre-grinding
Precision: AA,AAAA DIN3968
Material: Tungsten Carbide, high speed steel, powder metallurgy high speed steel
Application: Carbide Hob for Gleason cutting machine / Carbide Hob for OERLIKON bevel gear cutting machine
| specification | ||||||
| m | ∅D | ∅d | L | ∅D1 | L | |
| 8type | 0.1~0.15 | 25 | 8 | 8 | 17.5 | 0.5 |
| 0.2~0.3 | 25 | 8 | 10 | 17.5 | 0.5 | |
| 0.35~0.8 | 25 | 8 | 12 | 17.5 | 0.5 | |
| 10type | 0.2~0.25 | 32 | 10 | 12 | 22.5 | 1 |
| 0.3~0.45 | 32 | 10 | 15 | 22.5 | 1 | |
| 0.5~1.0 | 32 | 10 | 20 | 22.5 | 1 | |
